Product Details:
Payment & Shipping Terms:
|
| Rated Capacities(Emax): | 30KN | Recommended Excitation: | 10-12V DC |
|---|---|---|---|
| Material: | Stainless Steel | Model No.: | HZFS-033 |
| High Light: | 30kN Stainless Steel Load Cell,IP66 Stainless Steel Load Cell,12V DC pressure load cell |
||
HZFS-033 Stainless Steel Mini Load Cell Force Sensor 30kN IP66 for weighing instruments
Detailed Product Description
Rated capacities(Emax): 30kN
Recommended Excitation: 10-12V DC
Material: Stainless Steel
| Items | UNIT | TECHNICAL DATA |
|---|---|---|
| Rated capacities(Emax) | N | 30k |
| Sensitivity | mV/V | 1.0±0.5 |
| Total error | F.S | ≥1% |
| Creep error(30min) | F.S | ±0.1% |
| Zero balance | F.S | ±1% |
| TCO | F.S/℃ | ±0.2% / 10 |
| TC SPAN | F.S/℃ | ±0.5% / 10 |
| Input impedance | Ω | 350±50 |
| Output impedance | Ω | 352±3 |
| Insulation impedance | MΩ | ≥5000 |
| Temperature range, operating | ℃ | -30~ +70 |
| Maximum safe overload | F.S | 150% |
| Ultimate overload | F.S | 200% |
| Excitation, recommend | V | 10-12V DC |
| Excitation, maximum | V | 15V DC |
| Protection class | IP66 | |
| Construction | Stainless steel | |
| Wiring | Exc+(Red) Exc-(Black) Sig+(Green) Sig-(White) |
