22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg

22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg
22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg

Large Image :  22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg

Product Details:

Place of Origin: China
Brand Name: inntronic
Model Number: IN266

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: Negotiable
Delivery Time: 15-30days
Payment Terms: T/T
Supply Ability: 1000pcs/month
Detailed Product Description
Pattern: SILO SCALE COMPRESSION LOAD CELL Capacity: 1t-300t
Output: 2mv/v Material: Alloy Steel
Application: Silo Scale Interchangeable Brand: HBM
7.IP Protection Standard: IP 67 Accuracy Grade: C3
Cable Length: 2m Size: 1t:diameter: 62 Heignt:22mm
High Light:

22mm Shear Beam Load Cell

,

IP67 Shear Beam Load Cell

,

tension compression load cell 1000kg

IN266 1t to 300t Tension and Compression silo Load Cell for silo scale



  •  Alloy steel Load Cell
  •  Capacity from 1,000kg...300,000kg





PARAMETER UNIT TECHNICAL DATA
Rated capacity (Emax) kg 25/50/200/500/1,000/2,000/3,000/5,000/10,000/20,000/30,000
Accuracy class   0.3
Sensitivity mV/V 2.0 10%
Zero balance mV/V 0.04
Creep over 30min % 0.1
Temperature effect on zero %/ 0.0012
Temperature effect on output %/ 0.0023
Hysteresis % 0.017
Linearity deviation % 0.017
Repeatability % 0.017
Nominal temperature range 22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg 0 -10 to +40
Service temperature range 22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg 1 -10 to +50
Limit load % of R.C. 150
Break load % of R.C. 300
Nominal excitation V 5~12
Max. excitation V 15
Input impedance 22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg 2 400 25
Output impedance 22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg 3 350 3
Insulation resistance M >2000
Cable length M 2
Cable type   4 conductors, Braid Shielded, Black PVC Jacket
Color code   +Exc-Red, +Sig -Grn, -Exc-Blk, -Sig- Wht
Construction   Alloy steel
Protection class to IEC529   IP 67



22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg 4

 22mm IP67 Shear Beam Load Cell Miniature Load Cell Tension Compression 1000kg 5
